Non-Polarizing Beam Splitter Cube, 8 mm, with Mounted Lenses
EUR 60
Buy this product on eBay
Please note: if this product appears on the eBay page with the status
“ended”, please contact us via email or eBay messaging and the listing
will be reactivated specifically for your purchase.
Product Description
Non-polarizing beam splitter cube designed for visible spectrum applications, supplied with mounted converging and diverging lenses.
The beam splitter is non-polarizing over the entire visible range (400–700 nm), with an R/T ratio close to unity in the 620–700 nm spectral region.
Mounted optics:
• Converging lens: focal length approximately 25–30 mm
• Diverging lens: focal length approximately −15 to −20 mm
Please note that the focal distances were roughly evaluated and not laboratory measured.
Suitable for experimental optics setups, beam shaping, alignment tasks, and laboratory prototyping.
Technical Specifications
| Product Code | nepo-L |
| Optical Element | Non-polarizing beam splitter cube |
| Cube Size | 8 mm |
| Spectral Range | 400 – 700 nm |
| R/T Ratio | ≈ 1 (620 – 700 nm) |
| Coating | Dielectric |
| Converging Lens Focal Length | ≈ 25 – 30 mm |
| Diverging Lens Focal Length | ≈ −15 – −20 mm |
